Product Description

POM Sheet

Color:White,Black,Blue and so on.
Size:1000X2000X(Thickness:1-200mm),1220X2440X(Thickness:1-200mm)
600X1200X(Thickness:1-200mm)

Data Sheet

Property		Item No.	Unit	POM-C	POM-H	POM-H+PTFE
Mechanical Properties	1	Density	g/cm3	1.41	1.43	1.50
	2	Water absorption(23ºC in air)	%	0.20	0.20	0.17
	3	Tensile strength	MPa	68	78	55
	4	Tensile strain at break	%	35	35	10
	5	Compressive stress(at 2%nominal strain)	MPa	35	40	37
	6	Charpy impact strength (unnotched)	KJ/m²	≥150	≥200	≥30
	7	Charpy impact strength (notched)	KJ/m²	7	10	3
	8	Tensile modulus of elasticity	MPa	3100	3600	3200
	9	Ball indentation hardness	N/mm²	140	160	140
	10	Rockwell hardness	–	M84	M88	M84

POM resins (polyoxymethylene or POM) are engineering thermoplastics based on formaldehyde polymerization technology. POMresins have high tensile strength, stiffness, resilience, fatigue endurance, a low coefficient of friction against metals, POM and other plastics and moderate toughness. The polyoxymethylene sheet has high resistance to organic solvents, excellent dimensional stability, a low coefficient of friction and outstanding abrasion resistance among thermoplastics.

polyoxymethylene resistance to creep is excellent. Moisture, lubricants and solvents have little effect on this property, which is important in parts incorporating self-threading screws or interference fits. Good electrical properties qualify these materials for electrical applications requiring long-term stability. POM copolymers retain much of their toughness through a broad temperature range and are among the most creepresistant of the crystalline thermoplastics. A low moisture absorption characteristic permits molded parts to serve reliably in environments involving humidity variations.
